FW-600
The FireWire hub provides IEEE-1394a compliant ports that support data transfer rates of 100, 200 and 400 Mbps (megabits per second); and automatically switch to the highest speed that the peripheral supports. FireWire peripherals connect externally by simply plugging in the cables. Configuration is automatic - there is no need to specify memory addresses, IRQ assignments, device IDs, or to plug in terminators. IEEE-1394 compliant peripherals can be hot swapped (added and removed without shutting down the computer). The fastest growing use of FireWire is in the real of digital video (DV) devices. The digital format provides precise audio and video capabilities that are more directly compatible with a computer than the older generation of analog video devices.
 |
Performs IEEE-1394a function with high speed of 100/200/400 Megabits per second |
|
Enables a PC to connect consumer electronic devices by hot-plugging hookup |
|
IEEE 1394-1995 compliant and compatible with proposal 1394a |
|
Easy connection your Digital camcorder,D8, scanner and VCRs |
|
Supports plug & play specification |
|
Compact size for easy installation anywhere |
|
Supports up to 63 devices that can run simultaneously on a computer |
| Chip | TI | ||||||||
| IEEE-1394 Speed | 100/200/400 Mbps | ||||||||
| LED | 1 | ||||||||
| Device Port Connector | IEEE-1394a 6P Female x 6 | ||||||||
| Power Mode | Bus or Self Power / 12V 2A | ||||||||
| Cable Length | 1m | ||||||||
| Housing | Plastic | ||||||||
| Dimension ( L x W x H ) | 102 x 52 x 26mm | ||||||||
|
Windows OS: 98SE/Me/2000/XP/Vista/7/8/8.1/10 |
|
Mac OS: 8.6/9.x/10.x |
 |
 |
 |
 |
 |
.jpg) |
FW-300B
3 Port Repeater Hub provides port expansion on FireWire 800 IEEE-1394b device chains. The platform agnostic device provides three 9 pin (bilingual) IEEE-1394b ports with a maximum throughput of up to 800 Mbps each. The Hub utilizes IEEE-1394b bus power, or accepts an optional power adapter for use with devices requiring more power. Repeater hubs provide bus flexibility in that they allow for daisy chaining and/or hierarchical (tree) bus configurations. Repeater hubs also provide a means to lengthen the distance between devices when 1394b cable length of 4.5 meters (15 feet) is inadequate.
|
IEEE1394b & IEEE1394a compliant |
|
Supports data transfer rates of: 800, 400, 200 & 100Mbps |
|
Bus powered or self powered operation |
|
Hot plug and hot swap support |
|
Any port can be used to connect the computer or the devices |
|
Can be daisy-chained to support up to 63 devices |
|
Supports transfer distances of up to 4.5m |
|
LED power and port indicators |
| Chip | TI | ||||||||
| Speed | 800/400/200/100 Mbps | ||||||||
| LED | 4 | ||||||||
| IEEE-1394 Specification | IEEE-1394 a/b compliant | ||||||||
| Connector | IEEE-1394b 9P Female x 3 | ||||||||
| Power Mode | Bus powered or external power adapter | ||||||||
| Dimension (LxWxH) | 100 x 58 x 15mm | ||||||||
| Power Consumption | DC 12V1.5A (3.5x1.35) | ||||||||
|
Windows OS: 98SE/Me/2000/XP/Vista/7/8/8.1/10 |
|
Mac OS: 8.6/9.x/10.x |
 |
|
|
|
|
.jpg) |
