USB Isolator

USB-ISO101 ~Hot~

USB Isolator protects PC or Laptop while connecting USB peripherals which is wired to high voltage. This small, industrial - grade isolator is very easy to use and provides a high-voltage barrier protection against surges, noise and ground loop errors. It is suitable for use in sensitive applications like automotive measurements. USB isolator provides a high - voltage isolation barrier between computer and it’s connected USB device. The isolation protects equipment from electrical over-voltages and transient voltage spikes, by eliminating ground loop currents flowing between the PC and USB device which can cause damage and inaccurate measurements. Additionally, isolation minimizes conducted noise from static discharge, magnetic fields and radio frequency interference. USB isolator is USB bus powered and can provide 5V 300mA to your USB device with built-in isolated DC-DC converter. This is possible only when the isolator is connected to a high power USB host port.

USB isolation 5000V DC between USB host and USB device

Fully Compliant with USB specification 1.1 and 2.0, 1.5Mbps low speed and 12Mbps full speed Bi-directional communication

Short circuit protected for x D+ and x D- lines

Isolated power supply in device through a DC-to-DC converter

Class 3A contact ESD performance per ANSI/ESD STM5.1-2007

High common-mode transient immunity: >25 kV/us

Supports Windows 98SE / ME / 2000 / XP / Vista / 7 / 8 / 8.1 / 10; Mac OS 8.6 / 9.x / 10x or higher

No driver installation required

	Isolation D+ & D-			5000V DC

	Isolation Power			3000V DC

	Transfer Rate			1.5/12 Mbps

	Connector Host			USB Type A Male

	Connector Device			USB Type A Female

	Operating Temperature			0°C to 50°C

	Cable Length			0.15m

	LED			1

	Downstream Power			Up to 300mA

	Power Mode			Bus powered

	Housing			Plastic

	Dimension ( LxWxH )			66 x 39 x 20mm

	USB Specification			USB 1.1/2.0 compliant

	Windows OS: 98SE/ME/2000/XP/Vista/7/8/8.1/10 or higher
	Mac OS: 8.6/9.x/10.x or higher
