DP-14R ~New~
DP-14R integrates a point-to-point connection DisplayPort Repeater to simplify system equipments; and lower cost for applications requiring single DisplayPort input and output device in personal computing system and other emerging digital appliances.
*Remarks: The cascading length depends on the cable quality. Strongly recommends using the certified DP cables.
*Remarks: The cascading length depends on the cable quality. Strongly recommends using the certified DP cables.
 |
Supports UHD resolutions up to 7680 X 4320 @60Hz & 3840 X 2160 @144Hz 4:2:2 10bit |
|
Supports data rates up to 8.1 Gbps / lane or 32.4 Gbps total |
|
Fully compliant with DisplayPort specification 1.4 HBR3, HDCP 2.3, HDR, DPCP |
|
Supports 4k @144Hz ( max. length: 2m in; 10m out ); 8K @30Hz ( max. length: 2m in; 10m out ) |
|
Enables cascading 5 levels at 4K 144Hz* |
|
Supports DP++ Dual Mode, compatible with HDMI, DVI or VGA adapters |
| Connectors Input | DisplayPort 20 Pin Female | ||||||||
| Connectors Output | DisplayPort 20 Pin Female | ||||||||
| UHD Resolution | 7680 X 4320 @60Hz | ||||||||
| Environment Operating Temp. | 5 ℃ ~ 40 ℃ | ||||||||
| Environment Storage Temp. | -20 ℃ ~ 60 ℃ | ||||||||
| Environment Humidity | 0~80% RH, Non-condensing | ||||||||
| Power Supply | 5VDC 1A | ||||||||
| LED | 1 | ||||||||
| Housing | Plastic | ||||||||
| Dimension ( L x W x H ) | 55 x 54 x 20 mm | ||||||||
|
Windows OS: 2000/XP/Vista/7/8/8.1/10 or higher |
|
Mac OS: 9.x/10.x or higher |
|
Linux OS |
 |
 |
 |
 |
 |
 |
DP-R01-130
DP-R01-130 integrates a point-to-point connection DisplayPort Repeater to simplify system equipments; and lower cost for applications requiring single DisplayPort input and output device in personal computing system and other emerging digital appliances
|
Supports DisplayPort resolutions up to 4K 60Hz. |
|
Compliant with DisplayPort specification 1.2,HDCP 2.2 & DPCP |
|
Supports 4K 60Hz (max. length: 5m in; 5m out); 4K 30Hz (max. length: 15m in; 20m out); 2560 x 1600 60Hz (max. length: 10m in; 20m out) |
|
Supports DP++ Dual Mode, compatible with HDMI, DVI or VGA adapters. |
| Model No. | DP-R01-130 | ||||||||
| Input Connector | DisplayPort 20Pin Female | ||||||||
| Output Connector | DisplayPort 20Pin Female | ||||||||
| Resolution | 4K @60Hz | ||||||||
| LED | 1 | ||||||||
| Housing | Plastic | ||||||||
| Power Supply | DC5V 1A | ||||||||
| Dimension(LxWxH) | 55 x 54 x 20 mm | ||||||||
|
Windows OS: 2000/XP/Vista/7/8/8.1/10 or higher |
|
Mac OS: 9.x/10.x or higher |
|
Linux OS |
|
|
|
|
|
.jpg) |
DP-CAT2E ~New~
The DisplayPort Extender over CAT.6 allows the installation of a Hi-Def display up to 40 meters away from a DisplayPort source using two CAT.6 cables. Resolutions can be up to 3840 x 2160 @30Hz over two CAT. 6 24AWG cablings. HDCP is also supported. The Receiver is powered by the 2nd CAT.6 cable that extends the DisplayPort signal from the Transmitter, eliminating the need for an external power supply on the Receiver.
Note: the receiver may have power provided from the transmitter upon CAT.6 cabling connection. When the receiver is connected to an Active DisplayPort adapter, it requires an external power supply of 5V1A.
Note: the receiver may have power provided from the transmitter upon CAT.6 cabling connection. When the receiver is connected to an Active DisplayPort adapter, it requires an external power supply of 5V1A.
|
Extends DisplayPort audio and video up to 40 meters over 2 CAT.6 24AWG cablings |
|
Supports 8-Bit Deep Color; supports DisplayPort 1.1a |
|
Supports resolutions up to 3840 x 2160 @30Hz; 2560 x 1600 @60Hz; 2560 x 1440 @60Hz; 1920 x 1200 @60Hz; |
|
1920 x 1080 @60Hz over two CAT.6 24AWG cablings. |
|
HDCP compliant; supports the Active DisplayPort adapters |
|
16-position EQ rotary switch to compensate for cable skew, enables HPD auto calibration |
|
Power On LED indicator; no external power supply requirement on the receiver |
|
Supports 2.1 stereo audio out; Enables the DisplayPort signal transmitting to HD audio out. |
|
Rugged & cambered shape’s Aluminum enclosures are prefect for professional and industrial applications; surface-mountable |
| Connector Transmitter Input | DisplayPort 20 Pin female | ||||||||
| Connector Transmitter Output | RJ-45 female x 2 | ||||||||
| Connector Transmitter Audio | 3.5mm Jack | ||||||||
| Connector Receiver Input | RJ-45 female x 2 | ||||||||
| Connector Receiver Output | DisplayPort 20 Pin female | ||||||||
| Connector Receiver Audio | 3.5mm Jack | ||||||||
| Interconnection Cable | CAT.6 24AWG Cabling | ||||||||
| DP Cbl ext. on 4k@30Hz Input | 1m | ||||||||
| DP Cbl ext. on 4k@30Hz Output | 2m | ||||||||
| Operating Distance | Up to 40m | ||||||||
| Video Data Rate | Up to 2.7Gb/s | ||||||||
| Resolution Range | Up to 3840 x 2160 @30Hz | ||||||||
| LED | 1 | ||||||||
| Operating Temperature | 0°C to 40°C | ||||||||
| Power Supply Transmitter | 5V1A | ||||||||
| Power Supply Receiver | *optional | ||||||||
| Housing | Aluminum | ||||||||
| Dimension ( L x W x H ) | 90 x 73 x 31mm | ||||||||
|
Windows OS: 2000/XP/Vista/7/8/8.1/10 or higher |
|
Mac OS: 8.6/9.x/10.x or higher |
|
|
|
|
|
|
KVM-U3DP ~New~
The 2-Port USB 3.0 4K DisplayPort KVM Switch has a high quality and durability system to control two computers from one console of DP monitor, 2.1 surround sound audio, keyboard & mouse; shares with two USB 3.0 hubs. This KVM switch was rigorously tested with the most popular OS including Windows®, Linux® and Mac computers. It features 4K video resolution and allows users to access two 4K-enabled computers from a single USB keyboard & mouse, and DisplayPort video console.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Windows OS: 2000/XP/Vista/7/8/8.1/10 or higher |
|
Mac OS: 9.x/10.x or higher |
|
Linux OS |
|
|
|
|
|
|
DP-14S ~New~
The 8K DisplayPort 1.4 Switch can display live audio and video contents on single monitor from 2 UHD video sources that have double DisplayPort outputs. It is backward compatible to either HDMI or DVI, and can be well adapted to accommodate these older technologies with appropriate adapter cables. The 8K DisplayPort 1.4 Switch is robust and durable with remarkable Aluminum housing. IR Remote Control is an optional add-on for switching and power on/off. Users can switch among 2 different UHD video sources that have double DisplayPort outputs with ease by push button; or IR remote control at hand, so it is very flexible in controlling over video contents on display.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Windows OS: 2000/XP/Vista/7/8/8.1/10 or higher |
|
Mac OS: 9.x/10.x or higher |
|
Linux OS |
|
|
|
|
|
|
DP-201R
The 2-Port DisplayPort Switch can display live audio and video contents on single monitor from 2 DisplayPort output sources. It is backward compatible to either HDMI or DVI, and can be well adapted to accommodate these older technologies with appropriate adapter cables. The 2-Port DisplayPort Switch is robust and durable with remarkable Aluminum housing. IR Remote Control is an optional add-on for switching and power on/off. Users can switch among 2 different DisplayPort output sources with ease by push button; or IR remote control at hand, so it is very flexible in controlling over video contents on display.
|
Compliant with DisplayPort 1.2 |
|
Supports DP++ Dual Mode, HDCP 2.2 & DPCP |
|
Routing any DisplayPort source from among two different DisplayPort to one monitor with sound support. |
|
Supports memory function and enables to retrieve the previous port while restarting the unit. |
|
Supports DisplayPort Resolution up to 4k2k @60Hz |
|
Supports audio 7.1 Ch up to 192 kHz sample rate |
|
Enable switching and power on/off by IR remote control or push button |
| Model No. | DP-201R | ||||||||
| Input Connector | DisplayPort 20 Pin x 2 | ||||||||
| Output Connector | DisplayPort 20 Pin x 1 | ||||||||
| Frequency Bandwidth | 21.6Gbps ( 4 lanes at 5.4Gbps ) | ||||||||
| Video Resolution | 4k2k @60Hz | ||||||||
| LED | 2 | ||||||||
| Push Button | 1 | ||||||||
| IR remote control | Yes | ||||||||
| Power Supply | 5VDC 1A | ||||||||
| Cable Ext.length_Input | 1m (based on 4K@60Hz) | ||||||||
| Cable Ext.length_Output | 3m (based on 4K@60Hz) | ||||||||
| Housing | Aluminum | ||||||||
| Dimension ( L x W x H ) | 90 x 73 x 31mm | ||||||||
|
|
|
|
|
|
IVS-210
This product is a signal booster and duplicator which can take video input from a single source, broadcast and display it on two monitors using analog signals in a distance up to 210 feet. It features a signal bandwidth of 450MHz; it is almost 60 times greater than a simple TV to apply. High resolution setting of 2048x1536 in 24 or 32-bit true color mode will also secure the high quality of the video graphic images to be displaying. It’s ideal for an environment of education, meeting and commercial demonstration.
|
Easily installs into a spare back-plate slot in your PC (does not use a PCI or ISA expansion slot) |
|
Connects to an internal 5 1/4” power connector |
|
DDC2 function supports “Plug & Play” monitors |
|
Signal transmission distance of up to 210 feet |
|
Supports SVGA, VGA, XGA, QXGA and Multi-sync compliant monitors |
|
Supports 450 MHz video bandwidth |
|
Supports video resolution 2048 x 1536 @85 Hz; DDC, DDC2, DDC2B |
| Graphic Standards Compliant | VGA, XGA, QXGA and Multi-sync | ||||||||
| Connectors Input | HD-15 Male x 1 | ||||||||
| Connectors Output | HD-15 Female x 2 | ||||||||
| Power Mode | Bus powered | ||||||||
| Video Resolution | 2048x1536 @85 Hz | ||||||||
| VGA Bandwidth | 450 MHz | ||||||||
| Signal Transmission Distance | Up to 210 feet | ||||||||
| Power Consumption | DC5V | ||||||||
|
Windows: 98SE/ME/2000/XP/Vista/7/8 |
|
Mac & SUN |
|
 |
|
|
|
|
TAS-201
This optical audio auto switch allows two digital optical fiber inputs source to one output device such as speakers, amplifier, receiver or HDTV set. This optical audio auto switch also boosts the digital audio signals to 10m on either side (input and output total 20m) without any sonic quality loss after the cable run, making this digital optical audio switch an excellent choice for home setup and professional centre .This digital audio switch supports all S/PDIF digital audio transmission such as uncompressed PCM/LPCM and bitstream Dolby AC-3, Dolby 5.1, Dolby Digital, DTS and ADAT.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|
VGA-201A
VGA-201A is 2 Way Switch Box.Whether you are a computer technician or just a PC user, a Video Switch is a great tool for sharing one Monitor between 2 systems (or vice versa).
|
Uses to switch between two computers and one VGA monitor or switch between two monitors and one computer |
|
If you have an LCD monitor you will need to use the high resolution switch box |
|
Supports stereo audio |
|
High resolution video up to 2048 x 1536 |
|
Supports VGA, SVGA, XGA, SXGA, UXGA, QXGA and Multi-sync monitors |
|
Easy to install with no power required |
| Signal Type | VGA, SVGA, XGA, SXGA,UXGA, QXGA | ||||||||
| Video Connector | HD-15 Female x 3 | ||||||||
| Audio Connector | 3.5 x 1.35mm Audio Jack x 3 | ||||||||
| Video Resolution | 2048 x 1536 @60Hz | ||||||||
| VGA Bandwidth | 450 MHz | ||||||||
| Housing | Plastic | ||||||||
| Dimension(L x W x H) | 155 x 98 x 29 mm | ||||||||
| Power Mode | Bus powered | ||||||||
|
|
|
.jpg) |
|
|
VIS-110S
The 2 Port Video Switch allowing you to switch between 2 different computers’ video signals using a single VGA display .The Video Switch also acts as a signal booster, increasing the distance of the video signal up to 180 feet. A push button offers instant switching between users. The Video Switch is the ideal solution for meetings and conferences with multiple presenters.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|
VGA-201 ~Hot~
VGA-201 2 Way Switch Box. Whether you are a computer technician or just a PC user, a Video Switch is a great tool for sharing one Monitor between 2 systems (or vice versa).
|
Uses to switch between two computers and one VGA monitor or switch between two monitors and one computer. |
|
If you have an LCD monitor you will need to use the high resolution switch box |
|
High resolution video up to 2048 x 1536 |
|
Supports VGA, SVGA, XGA, SXGA, UXGA, QXGA and Multi-sync monitors |
|
Easy to install with no power required. |
| Signal Type | VGA, SGA, XGA, SXGA, UXGA, QXGA | ||||||||
| Video Connector | HD-15 Female x 3 | ||||||||
| Video Resolution | 2048 x 1536 @60 Hz | ||||||||
| VGA Bandwidth | 450 MHz | ||||||||
| Housing | Plastic | ||||||||
| Dimension(LxWxH) | 155 x 98 x 29 mm | ||||||||
| Power Mode | Bus powered | ||||||||
|
|
|
.jpg) |
|
|
CVM-810S
This Video Separator is a signal booster and splitter that input video signal from a single source and then direct it to 8 analog signals video monitors. The signal boost allows you not only splitting the signal but also extend the signal to 210 feet distance. If you want to display the same information on many monitors at once, such as in different classrooms or at demonstration, this product can performs incredibly well. Bandwidth is the term that is used to describe the signal capacity for data transmitted per unit of time. This unit has a bandwidth of 450MHz and that is almost 60 times greater than a simple TV signal. This huge bandwidth allows transmission of large amounts of information at a very high speed rate, and thus one can use very high-resolution setting of 2048x1536 in 24 or 32-bit true color mode.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|
CVM-410S
This Video Separator is a signal booster and splitter that input video signal from a single source and then direct it to 4 analog signals video monitors. The signal boost allows you not only splitting the signal but also extend the signal to 210 feet distance. If you want to display the same information on many monitors at once, such as in different classrooms or at demonstration, this product can performs incredibly well. Bandwidth is the term that is used to describe the signal capacity for data transmitted per unit of time. This unit has a bandwidth of 450MHz and that is almost 60 times greater than a simple TV signal. This huge bandwidth allows transmission of large amounts of information at a very high speed rate, and thus one can use very high-resolution setting of 2048x1536 in 24 or 32-bit true color mode.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
.jpg) |
|
|
CVM-210SM1
This Video Separator is a signal booster and splitter that input video signal from a single source and then direct it to 2 analog signals video monitors. The signal boost allows you not only splitting the signal but also extend the signal to 210 feet distance. If you want to display the same information on many monitors at once, such as in different classrooms or at demonstration, this product can performs incredibly well. Bandwidth is the term that is used to describe the signal capacity for data transmitted per unit of time. This unit has a bandwidth of 450MHz and that is almost 60 times greater than a simple TV signal. This huge bandwidth allows transmission of large amounts of information at a very high speed rate, and thus one can use very high-resolution setting of 2048x1536 in 24 or 32-bit true color mode.
|
One video input with 2 video outputs |
|
Transmission distance of up to 210 feet |
|
Suitable for SVGA, VGA, XGA,QXGA and Multi-sync monitors |
|
Daisy-chain multiple units together for even more outputs |
|
Supports 450 MHz video bandwidth |
|
Supports Video resolution 2048 x 1536 @85Hz; DDC, DDC2, DDC2B |
| Signal Type | SVGA, VGA, XGA, QXGA and Multi-sync | ||||||||
| Connectors Input | HD-15 Female x 1 | ||||||||
| Connectors Output | HD-15 Female x 2 | ||||||||
| Video Resolution | 2048 x 1536@85Hz | ||||||||
| Bandwidth | 450 MHz | ||||||||
| Cable Distance | 210 feet | ||||||||
| Housing | Metal | ||||||||
| Dimension ( L x W x H ) | 200 X 75 X 42 mm | ||||||||
| Power Mode | External power adapter | ||||||||
| Power Consumption | DC 5V1A(Plug 5.5x2.1 mm) | ||||||||
|
|
|
.jpg) |
|
|
CVM-210S
This Video Separator is a signal booster and splitter that is used to take video input from a single source and direct it to 2 video outputs for monitors using analog signals. The signal boost allows you to not only split the signal but also to extend the signal up to far 210 feet in distance. If you want to display the same information on many monitors at once, such as in a classroom environment, or at a demonstration, this product performs incredibly well. Bandwidth is the term that is used to describe the signal capacity of these units. In general, bandwidth is directly proportional to the amount of data transmitted per unit of time. These units have a bandwidth of 450MHz and that is almost 60 times greater than a simple TV signal. This huge bandwidth allows for the transmission of large amounts of information at a very high rate of speed, and thus you can use the very high-resolution setting of 2048 x 1536 in 24 or 32-bit true color mode.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
CVM-C21
This Video Separator is a signal booster and splitter that input video signal from a single source and then direct it to 2 analog signals video monitors. The signal boost allows you not only splitting the signal but also extend the signal to 180 feet distance. If you want to display the same information on many monitors at once, such as in different classrooms or at demonstration, this product can performs incredibly well. Bandwidth is the term that is used to describe the signal capacity for data transmitted per unit of time. This unit has a bandwidth of 450MHz and that is almost 60 times greater than a simple TV signal. This huge bandwidth allows transmission of large amounts of information at a very high speed rate, and thus one can use very high-resolution setting of 2048x1536 in 24 or 32-bit true color mode.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|
PSM-210VS
This product is a signal booster and duplicator which can take video input from a single source, broadcast and display it on two (2) monitors using analog signals in a distance up to 210 feet. It features a signal bandwidth of 450MHz; it is almost 60 times greater than a simple TV to apply. High resolution setting of 2048x1536 in 24 or 32-bit true color mode will also secure the high quality of the video graphic images to be displaying. It’s ideal for an environment of education, meeting and commercial demonstration.
|
One video input with two (2) video outputs |
|
Signal transmission distance of up to 210 feet |
|
Supports VGA / SVGA / XGA / QXGA and Multi-sync compliant monitors |
|
Daisy-chained with multiple units generating more outputs |
|
Supports 450 MHz video bandwidth |
|
Supports Video resolution 2048 x 1536 @85Hz; DDC, DDC2, DDC2B |
| Graphic Standards Compliant | VGA/SVGA/XGA/QXGA and Multi-sync | ||||||||
| Connectors Input | HD-15 Female x 1 | ||||||||
| Connectors Output | HD-15 Female x 2 | ||||||||
| Power Mode | Bus powered | ||||||||
| Video Resolution | 2048 x 1536@85 Hz | ||||||||
| VGA Bandwidth | 450 MHz | ||||||||
| Signal Transmission Distance | Up to 210 feet | ||||||||
| Housing | Plastic | ||||||||
|
|
|
.jpeg) |
|
.JPG) |
CVM-410A
CVM-410A Video/Audio splitter also as known as Video/Audio Distribution Amplifier allows you to display the same image on up to 4 monitors from one PC. CVM-410A Video and Audio splitter is a fast, flexible solution for Test Bench Facilities, data centers, or video broadcasting such as remote monitoring, presentations, educational facilities, advertising and monitoring stock quotes.
|
Supports up to 450 MHz bandwidth |
|
Enhances video signals for distance up to 210 feet |
|
Can be cascaded for more outputs |
|
Stereo audio support |
|
Ideal for video broadcasting, remote monitoring, presentations, and educational facilities |
|
Supports VGA, SVGA, XGA, SXGA, UXGA, QXGA and Multi-sync monitors |
|
Supports Video resolution 2048 x 1536 @85Hz; DDC, DDC2, DDC2B |
| Signal Type | VGA, SVGA, XGA, SXGA | ||||||||
| Signal Type | UXGA, QXGA and Multi-Sync | ||||||||
| Video Input Connector | HD-15 Female x 1 | ||||||||
| Audio Input Connector | 3.5 x 1.35 mm Audio Jack x 1 | ||||||||
| Video Output Connector | HD-15 Female x 4 | ||||||||
| Audio Output Connector | 3.5 x 1.35 mm Audio Jack x 4 | ||||||||
| Video Resolution | 2048 x 1536 @85Hz | ||||||||
| VGA Bandwidth | 450 MHz | ||||||||
| Cable Distance | 210 Feet | ||||||||
| Power Mode | External power adapter | ||||||||
| Power Consumption | DC 5V1A(Plug 5.5x2.1 mm) | ||||||||
| Housing | Metal | ||||||||
| Dimension(L x W x H) | 163 x 77 x 25 mm | ||||||||
|
|
|
|
|
|
CVM-210A
CVM-210A Video /Audio splitter also as known as Video/Audio Distribution Amplifier allows you to display the same image on up to 2 monitors from one PC. CVM-210A Video and Audio splitter is a fast, flexible solution for Test Bench Facilities, data centers, or video broadcasting such as remote monitoring, presentations, educational facilities, advertising and monitoring stock quotes.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|
