USB-1024BC-ECO

The 10-Port Charging hub is a solution for quick charging up to 10 iPads, iPhones iPods and USB charging devices operating simultaneously. Also provides you a safe and secure facility for large capacity USB station in-house that supports Over-voltage, Over-current & Short circuit protections. Places such as school’s classroom, businesses conference or meeting in organizations.

Compliant with USB Battery Charging Spec 1.2

Enables to provide up to 2.4A output current on each port

Supports the iOS, Android devices

Intelligently detects the power current of each port by the sensing meter with firmware, and enables the port’s LED to illuminate its corresponding color.

Enables Green Energy function automatically shut down the hub when all devices are fully charged

Supports 2.5A Over-Current Protection and ±15kV (air), ±8kV (contact) ESD protection on each port.

Supports Over-voltage Protection & Short circuit Protection on each port

Supports 40A (5/50ns) & Peak Pulse Power 250 W (8/20 us) Surge and Transient spikes protection on each port

For the Over-heating protection, if the unit’s heat is over the setting, it would cut off all the output current immediately.

At the meantime, the whole LEDs of the 10 ports would be green blinking.

	Model No.			USB-1024BC-ECO

	Current per Port			DC5V 2.4A

	Connector			USB A Female x 10

	Power Supply			DC24V 6.25A (150W)

	Green Energy Button			Green Energy button x 1

	LED Charge Mode			Charging in progress: Red Color x 10

	LED Charge Mode			Disconnected or Fully charged: Green Color x 10

	LED Over-current Mode			Red Blinking x 10

	LED Short circuit Mode			Red/Green Alternate Blinking x 10

	Operating Temperature			0 ~ 40℃

	Housing			Metal

	Dimension (L x W x H)			268 x 102 x 40 mm

	Windows OS: 98SE/ME/2000/XP/Vista/7/8/8.1/10
	Mac OS: 8.6/9.x/10.x or later

See Larger Image

USB-220CH

USB-220CH is a 20-Port USB Hub with Charger, a solution for charging or sync of several iPads, iPhones iPods and USB charging devices operating simultaneously this is a perfect tool to eliminate the jumble of wires and chargers and also is ideal for large capacity USB station in-house for automated duplication tasks. Places such as school’s class room, businesses conference or meeting in organizations.

N.B.-We do not make any warranties regarding the accurate operation of this charger unit if the end user presumes to install the charging software like 'AI Charger' on computer for expanding the output current of charger unit.

Charges or syncs up to 20 iPads, iPods, iPhones or other USB-charged in charge mode devices, providing each USB port with the optimum charge level for each device

Will also charge virtually any other device that can be charged through a powered USB port

Supports High Speed 480Mbps, full speed 12Mbps and low speed 1.5Mbps operation

Fully Compliant with USB specification 1.1 and 2.0

Twenty (20) Hi-Speed USB 2.0 downstream ports

Supports Over-current detection and protection

Supports Surge protection, part ESD Protection (only for the DC contact with power supply)

Extends up to optimum 40 USB devices by connecting cascade port with another USB 2.0 charge hub(s); to see the notes in the spec. file

Supports Windows OS: 98SE/ME/2000/XP/Vista/7/8/8.1/10; Mac OS 8.6/9.x/10.x or higher

	Chip			Terminus

	Speed			480/12/1.5 Mbps

	USB Specification			USB 1.1/2.0 compliant

	Current per Port			5VDC 1100 mA

	Connector Upstream			USB B Female

	Connector Downstream			USB A Female x 20

	Connector Cascade			USB A Female

	Power Mode			External power adapter

	LED Charge Mode			Red Color x 20

	LED SYNC Mode			Orange Color x 20

	Cable Length			1.8m

	Dimension (L x W x H )			268 x 102 x 40 mm

	Windows OS: 98SE/ME/2000/XP/Vista/7/8/8.1/10
	Mac OS: 8.6/9.x/10.x or later

See Larger Image

USB-210CH

USB-210CH is a 10-Port USB Hub with Charger, a solution for charging or sync of several iPads, iPhones iPods and USB charging devices operating simultaneously this is a perfect tool to eliminate the jumble of wires and chargers and also is ideal for large capacity USB station in-house for automated duplication tasks. Places such as school’s class room, businesses conference or meeting in organizations.

Charges or syncs up to 10 iPads, iPods, iPhones or other USB-charged in charge mode devices, providing each USB port with the optimum charge level for each device

Will also charge virtually any other device that can be charged through a powered USB port

Supports High Speed 480Mbps, full speed 12Mbps and low speed 1.5Mbps operation

Fully Compliant with USB specification 1.1 and 2.0

Ten (10) Hi-Speed USB 2.0 downstream ports

Supports Over-current detection and protection

Supports Surge protection, part ESD Protection (only for the DC contact with power supply)

Extends up to optimum 20 USB devices by connecting cascade port with another USB 2.0 charge hub(s); to see the notes in the spec. file

Supports Windows OS: 98SE/ME/2000/XP/Vista/7/8/8.1/10; Mac OS 8.6/9.x/10.x or higher

	Chip			Terminus

	Speed			480/12/1.5 Mbps

	USB Specification			USB 1.1/2.0 compliant

	Current per Port			5VDC 2.4 A

	Connector Upstream			USB B Female

	Connector Downstream			USB A Female x 10

	Cascade			USB A Female

	Power Mode			External power adapter

	LED Charge Mode			Red Color x 10

	LED SYNC Mode			Orange Color x 10

	Cable Length			1.8m

	Dimension (L x W x H )			268 x 102 x 40 mm

	Windows OS: 98SE/ME/2000/XP/Vista/7/8/8.1/10
	Mac OS: 8.6/9.x/10.x or later

See Larger Image

USB-2024BC ~New~

The 20-Port Charging hub is a solution for quick charging or sync up to 20 iPads, iPhones iPods and USB charging devices operating simultaneously; this is a perfect tool to effectively perform Sync/Charge Mode switching. Also is ideal for large capacity USB station in-house that enables charging and syncing at a time. Places such as school’s classroom, businesses conference or meeting in organizations.

Compliant with USB Battery Charging Spec 1.2

Enables to provide up to 1.5A at Sync (CDP mode) or 2.4A at Charge (DCP mode) output current on each port. Supports the iOS, Android devices.

Enables Sync/Charge mode switching upon manually connecting or disconnecting host port.

Intelligently detects the power current of each port by the sensing meter with firmware, and enables the port’s LED to illuminate its corresponding color.

Enables Green Energy function automatically shutdown the hub when all devices are fully charged at Charge mode.

Supports Over-Current Protection and ±15kV (air), ±8kV (contact) ESD protection on each port.

Supports 40A (5/50ns) & Peak Pulse Power 250 W (8/20 us) Surge and Transient spikes protection on each port.

For the High-temp protection, if the unit’s high temperature is over the setting, it would cut off all the output current immediately.

The rear fans spec: SUNON Vapo DC Fan; Life Expectancy: 60,000 hours

Enables to start/cut off the fans automatically according to the temperatures setup.

	Model No.			USB-2024BC

	Current per Port SYNC Mode			DC5V 1.5A

	Current per Port Charge Mode			DC5V 2.4A

	Speed			480/12/1.5 Mbps

	USB Specification			USB 2.0/1.1/1.0 compliant

	Connector Upstream			USB B Female

	Connector Downstream			USB A Female x 20

	Connector Cascade			USB A Female

	Power Supply			DC12V 24A (288W)

	Green Energy Button			Green Energy button x 1

	LED Charge Mode			Charging in progress: Red Color x 20

	LED Charge Mode			Disconnected or Fully charged: Green Color x 20

	LED SYNC Mode			Orange Color x 20

	Operating Temperature			0 ~ 40℃

	Housing			Metal

	Dimension (L x W x H)			268 x 102 x 40 mm

	Windows OS: 98SE/ME/2000/XP/Vista/7/8/8.1/10
	Mac OS: 8.6/9.x/10.x or later

See Larger Image

USB-1524BC

The 15-Port Charging hub is a solution for quick charging and/or sync up to 15 iPads, iPhones iPods and USB charging devices operating simultaneously; this is a perfect tool to effectively perform Sync/Charge Mode switching. Also is ideal for large capacity USB station in-house that enables charging and syncing at a time. Places such as school’s classroom, businesses conference or meeting in organizations.
