UTS-485X + DT485C
USB to RS-485 adapter provides an extra serial com port via USB connection and can be configured to work with RS-485 peripherals such as POS and industrial controlled devices. The USB adapter supports an easy serial port expansion and requires no IRQ, DMA, or I/O port resources. The USB adapter features a full set of RS-485 data and control signals on its DB-9 or terminal block changer. It supports data transfer rates of up to 3M baud. It receives full power via the host USB connection, and provides power to the attached serial device without requiring an external power adapter.
 |
Fully Compliant with USB specification 1.1 and 2.0 |
|
Allows up to 256 nodes on the bus |
|
±15kV HBM ESD Protected |
|
Supports data transfer rates up to 3M baud |
|
Supports remote wake-up and power-on-reset |
|
Compatible with Windows 98SE / ME / 2000 / XP / Vista / 7 / 8 / 8.1 / 10; Win CE, Windows server 2003 / 2008 / 2008R2 / 2012 / 2012R2; Mac OS 8.6 / 9.x / 10.x, Linux 1.5.0 or higher |
|
Changer adapter from DB-9F to 5 Pins Terminal block |
| Chip | FTDI | ||||||||
| Data Transfers Rates | 300 to 3M baud | ||||||||
| Power Consumption | 56mA | ||||||||
| LED | 3 | ||||||||
| Environment Operating Temp | 0 ℃ ~ 40 ℃ | ||||||||
| Environment Storage Temp | -20 ℃ ~ 60 ℃ | ||||||||
| Environment Humidity | 0~80% RH, Non-condensing | ||||||||
| USB Specification | USB 1.1/2.0 compliant | ||||||||
| Interface | RS-485 | ||||||||
| Connector Host | USB Type A Male | ||||||||
| Connector Device | DB-9M/DB-9F to Terminal Block | ||||||||
| Power Mode | Bus powered | ||||||||
| Housing | Plastic | ||||||||
|
Windows OS: 98SE/Me/2000/XP/Vista/7/8/8.1/10 or higher |
|
Windows server: 2003/2008/2008R2/2012/2012R2 or higher |
|
WinCE OS: V 4.2 ~ V7.0 |
|
Mac OS: 8.6/9.x/10.x or higher |
|
Linux OS: Kernel 1.5.0 or later |
 |
 |
 |
 |
 |
.jpg) |
UTS-422X + DT422C
USB to RS-422 adapter provides an extra serial com port via USB connection and can be configured to work with RS-422 peripherals such as POS and industrial controlled devices. The USB adapter supports an easy serial port expansion and requires no IRQ, DMA, or I/O port resources. The USB adapter features a full set of RS-422 data and control signals on its DB-9 or terminal block changer. It supports data transfer rates of up to 3M baud. It receives full power via the host USB connection, and provides power to the attached serial device without requiring an external power adapter.
|
Fully Compliant with USB specification 1.1 and 2.0 |
|
Allows up to 256 nodes on the bus |
|
±15kV HBM ESD Protected |
|
Supports the asynchronous serial interfaces |
|
Supports data transfer rates up to 3M baud |
|
Supports remote wake-up and power-on-reset |
|
Supports default ROM or external EEPROM for device configuration |
|
Compatible with Windows 98SE / ME / 2000 / XP / Vista / 7 / 8 / 8.1 / 10; Win CE, Windows server 2003 / 2008 / 2008R2 / 2012 / 2012R2; Mac OS 8.6 / 9.x / 10.x, Linux 1.5.0 or higher |
|
Changer adapter from DB-9 to Terminal block |
| Chip | FTDI | ||||||||
| Data Transfers Rate | up to 3M baud | ||||||||
| Power Consumption | 56mA | ||||||||
| LED | 3 | ||||||||
| Environment Operating Temp. | 0 ℃ ~ 40 ℃ | ||||||||
| Environment Storage Temp. | -20 ℃ ~ 60 ℃ | ||||||||
| Environment Humidity | 0~80% RH, Non-condensing | ||||||||
| USB Specification | USB 1.1/2.0 compliant | ||||||||
| Interface | RS-422 | ||||||||
| Connector Host | USB Type A Male | ||||||||
| Connector Device | DB-9 / Terminal Block | ||||||||
| Power Mode | Bus powered | ||||||||
| Housing | Plastic | ||||||||
|
Windows OS: 98SE/Me/2000/XP/Vista/7/8/8.1/10 or higher |
|
Windows server: 2003/2008/2008R2/2012/2012R2 or higher |
|
WinCE OS: V 4.2 ~ V7.0 |
|
Mac OS: 8.6/9.x/10.x or higher |
|
Linux OS: Kernel 1.5.0 or later |
|
|
|
|
|
.jpg) |
